I-UAV TUCANO
Airplane Conversion
View more
I-UAV VALKYRIE
Airplane Conversion
View more
| Range | 1,330 km |
| Cruise Speed | 520 km/h |
| Endurance | 8hrs 24mins |
| Wing Span | 11.14 m |
| Length | 11.38 m |
| Empty Weight | 3,200 kg |
| Payload Capacity | 1,500 kg |
| Maximum Speed | 590 km/h |
| Stall Speed | 148 km/h |
| g-limit | +7/-3.5 g |
| Combat Radius | 550 km |
| Ferry Range | 2,855 km |
| Service Ceiling | 10,668 m |
| Rate of Climb | 16.4 m/s |
| Height | 3.97 m |
| Wing Area | 19.4 m2 |
| MTOW | 5,400 kg |
| Powerplant: |
Hartzell 5-blade constant speed, fully feathering, reversible-pitch Pratt & Whitney Canada PT6A-68C turboprop, 1,196kw |
Conversion based on Pilatus PC21
| Range | 2000 km |
| Wing Span | 9.1 m |
| Length | 11.233 |
| Service Ceiling | 11580 m |
| Rate of Climb | 1219 m/min |
| Height | 3.749 m |
| MTOW | 4250 kg |
| Vmax | 685 km/h |
| Powerplant: |
Pratt & Whitney Canada PT6A- 68B Turboprop 1,200 kW 0.39 kW/kg |
1125kg
on four underwing stations
2X 30mm autocannon 300 rounds each
Satcom
Multi mode SAR GMTI
TAWS, terrain following system
4K EO/IR
full spectral range imaging
Laser illuminator, pointer and designator
Multiple wide FOV 4k IR/RGB pilot cameras
Full 360° awareness
Infrared and electronic countermeasures
